Fourstroke LT is an XC bike designed for riders who want even more performance. Offering trail-riding at speed with progressive 120mm of our updated APS dual-link suspension travel, there is no limit to what you and the Fourstroke LT can achieve. The full-carbon frame includes our most progressive BWC geometry now fitting two water bottles, integrated fork stopper and frame protection. Fourstroke LT ONE plays the trails with confidence with a SRAM GX Eagle drivetrain, RockShox SID Select+ fork and RockShox SIDLuxe Select+, DT Swiss M 1900 wheels with 30mm inner width and the Bikeyoke Divine seatpost.
Frameset
Frame:
Fourstroke LT Carbon | APS Suspension System | 120mm Travel | Fully Guided Internal Cable Routing | Post Mount Disc | 12 x 148mm Boost Thru-Axle
Suspension
Front Suspension:
RockShox SID Select+
Rear Suspension:
RockShox SIDLUXE Select+
Cockpit
Stem:
Truvativ Atmos 7K
Handlebar:
BMC MRB 03 | 760mm
Seat
Seatpost:
Bikeyoke Divine
Saddle:
Fizik Antares R7
Drivetrain
Crankset:
SRAM Stylo 6k Eagle
Chainrings:
32T
Cassette:
SRAM XG-1275 Eagle
Cassette Size:
10-52T
Chain:
SRAM NX Eagle
Rear Derailleur:
SRAM GX Eagle
Shifters:
SRAM GX Eagle
Gears:
1 x 12
Bottom Bracket:
PF92 Bottom Bracket
Brakes
Brake Levers / Calipers:
SRAM G2 RS
Rotors:
SRAM Centerline | 6-Bolt
Rotor Size (F/R):
180 / 180mm
Wheels
Rims:
DT Swiss M 1900 | 30mm Inner Width
Hubs (F/R):
DT Swiss 370 | Ratchet LN18
Tires:
Maxxis Rekon 2.4" | EXO TR
Tubeless Information:
Tubeless Ready Rims | Tubetype Tires
| Size | S | M | L | XL |
|---|---|---|---|---|
| Rider Height | <172 | 172-182 | 180-188 | >188 |
| Reach | 437 | 457 | 477 | 500 |
| Stack | 584 | 592 | 600 | 615 |
| Bar Rise | 15 | 15 | 15 | 15 |
| Bar Sweep | 9 | 9 | 9 | 9 |
| Bar Width | 760 | 760 | 760 | 760 |
| BB Drop | 38 | 38 | 38 | 38 |
| Crank Length | 165 | 170 | 175 | 175 |
| Fork Length | 530 | 530 | 530 | 530 |
| Fork Rake | 44 | 44 | 44 | 44 |
| Front Center | 711 | 743 | 760 | 790 |
| Head Tube | 84 | 93.5 | 101 | 118 |
| Head Tube Angle | 66.5 | 66.5 | 66.5 | 66.5 |
| Rear Center | 431 | 430.5 | 431 | 431 |
| Seat Angle | 76.7 | 76.7 | 76.7 | 76.7 |
| Seat Tube | 420 | 430 | 460 | 490 |
| Seatpost Drop | 150 | 160 | 160 | 185 |
| Standover Height | 727 | 727 | 727 | 767 |
| Stem Angle | 6 | 6 | 6 | 6 |
| Stem Length | 40 | 50 | 50 | 60 |
| Top Tube | 576 | 599 | 623 | 651 |
| Trail | 115 | 115 | 115 | 1115 |
| Wheelbase | 1140 | 1172 | 1189 | 1219 |
