Frameset
Frame:
Teammachine SLR Carbon with Aerocore Design | ICS Technology Stealth Cable Routing | Stealth Dropout Design | TCC Race compliance level | Flat Mount Disc | 12 x 142mm Thru-Axle | Optimized for Aerocore Bottle Cages
Fork:
Teammachine SLR Carbon | ICS Technology Stealth Cable Routing | TCC Race Compliance Level | Stealth Dropout Design | Flat Mount Disc | 12 x 100mm Thru-Axle | 48mm offset Size 47-51 | 43mm offset Size 54-61
Cockpit
Stem:
BMC RSM 01 | Integrated Cockpit System Technology
Handlebar:
BMC RAB 02 | Ergo Top Shape | Compact Bend [or] BMC HB D4 03, 0, 6 | Alloy 6061 | 135mm drop, 70mm reach, 6° flare
Seat
Seatpost:
Teammachine SLR Carbon D-Shaped Seatpost | 15mm Offset
Saddle:
Fizik Antares R7 | S-Alloy rail 140mm [or] Selle Italia Model X Superflow | FeC Alloy rail | 145mm
Drivetrain
Crankset:
SHIMANO 105 (FC-R7100)
Chainrings:
50-34T
Cassette:
SHIMANO 105 (CS-R7101)
Cassette Size:
11-34T
Chain:
SHIMANO CN-M6100
Front Derailleur:
SHIMANO 105 (FD-R7100)
Rear Derailleur:
SHIMANO 105 (RD-R7100)
Shifters:
SHIMANO 105 (ST-R7120)
Gears:
2 x 12
Bottom Bracket:
SHIMANO Press-Fit Bottom Bracket (BB-RS500-PB)
Brakes
Brake Levers / Calipers:
SHIMANO 105 (BR-R7170)
Rotors:
SHIMANO SM-RT70 | Centerlock
Rotor Size (F/R):
160 / 160mm
Wheels
Rims:
PRD23 | 23mm
Hubs (F/R):
SHIMANO HB-TC500-12 & FH-TC500-HL | Center Lock| 28H
Tires:
Pirelli P7 Sport | 26mm
Tubeless Information:
Non-Tubeless Rims | Non-Tubeless Clincher Tire
Additional Information
Tire Clearance:
30mm measured tire
Weight without Pedals:
8.5 kg
ASTM Classification:
Level 1
System Weight Limit:
110kg
General Product Safety Regulation (GPSR):
Safety Instructions GPSR (EU)
Responsible person according to GPSR (EU)
Color Reference
Color Code:
blk gry gry
